Quick Details

  • Place of Origin: Taiwan
  • Brand Name: ATLANTIS
  • Model Number: PT-300
  • Material: 1Cr18Ni9Ti
  • Pressure Range: -0.1MPa~-0.01MPa/0/0.01MPa~100.0MPa

Packaging & Delivery

Packaging Details To be discussed.
Delivery Time Upon qut.
Piezoresistive General Pressure Transmitter of Energy Industry
PT-300 Series

Features

1.Zero-point and measuring range adjustments are optional

2.Spot Display is optional

3.Digital compensation of total temperature is optional

4.Various pressure measuring ranges and output signals

5.Various electric connections and pressure interfaces

6.Non-polar 2 wire system current output

7.Intrinsic safety type E


Application

Air compressors, refrigerator, hydraulic control, farm equipment, pressure gauge, automatic monitoring systems, energy and water system, remote management of oil well and so on.


Specification

Material:   1Cr18Ni9Ti

Electric Connection:  DIN43650, protection IP65; Aviation plugs GX16-7, protection IP45; wire-tighter conduit, Case Protection IP68

Connection:  M20×1.5,G1/2,G1/4,G1,NPT1/2,NPT1/4,R1/4,custom-made options(Ht=____)

Working Temperature:  processing temperature:-40℃~85℃ (Custom-made options: -40℃~125℃);
compensation temperature: -10℃~70℃ (Custom-made options: total temperature compensation product)

Output Signal:  2-line system: 4-20mA; 3-line system: 0-20mA, 0~5V, 0.5~4.5V, 0.5~3V, 0~10V DC, 1~5V; 4-line system:  0~20mA or 0~5/10V
Response Time  10ms

Pressure Range:  -0.1MPa~-0.01MPa/0/0.01MPa~100.0MPa

Overload Pressure:  1.5 rated pressure

Breakaway Pressure:  3 rated pressure

Load Resistance:  2-line system: (U-10)/0.02(ohm);
3 & 4-line system: Current Type:(U-12)/0.02(ohm); Voltage Type: >20 kiloohm

Power:  2-line system: 10~30V DC; 3-line system: 11~30V DC, 8~24V DC; 4-line system: 5V Ratio, 8/11~30V DC

Electric Strength:  500V@60 second

Insulation:  >100M ohm@50V

Electromagnetic Compatibility:  EMC radiation:EN50081-1/-2; EMC susceptibility:EN50082-2

Stability:  Standard: 0.25% F.S., Max.: 0.4% F.S.

Accuracy:  ±0.25, ±0.5% F.S.
